Waukesha Cherry-Burrell Brand Universal TS Series
ITEM NO. DESCRIPTION
1 Nut, Acorn
2 Cover
Gasket, Cover, EPDM
3
* Gasket, Cover, FKM
Gasket, Cover, FFKM
4 Nut, Screw
Screw Nut O-ring EPDM
* 5
Screw Nut O-ring FKM
Screw Nut O-ring FFKM
6 Washer-Belleville
Washer Retainer O-ring EPDM
* 7
Washer Retainer O-ring FKM
Washer Retainer O-ring FFKM
Left Hand Screw 16.5 Pitch
8
Left Hand Screw 33 Pitch
Left Hand Screw 44 Pitch
Right Hand Screw 16.5 Pitch
9
Right Hand Screw 33 Pitch
Right Hand Screw 44 Pitch
10 Mechanical Seal Assembly
11 Body Retaining Screw
12 Cover Short Dowel Pin
13 Cover Short Dowel Pin
14 Bushing, Dowel Pin
15 Bushing, Dowel Pin
16 Pump Body
17 Gear Case Assy
18 SHCS 6-32 x .375 18-8 SS
19 Stud, Standard Cover
20 Gear Case Dowel
21 Gear Case Dowel
22 Eye Bolt 5/16-18 X .50"LG 304
Notes:
* Recommended spare part
1. See "Universal Twin Screw Seal Parts" on page 113.
POA: Contact customer service for part number.
06/2017
015-UTS Parts
QTY PER
PUMP
95-03141
PART NO. NOTES
8 109369+
1 POA
137424+
1
137422+
137423+
2 101804+
E70126
2
V70126
K70126
2 101691+
E70112
2
V70112
K70112
137363+
1
136792+
137365+
137362+
1
136791+
137364+
2 POA
2 137096+
1 137002+
1 137001+
1 AD0116100
1 AD0116000
1 POA
1 POA
6 119627+
8 137068+
1 124581+
1 124582+
2 30-719
PL5060-CH139
Parts List
1
Page 97
