Figure 3.7: Magnetic
Side View
3.3.4 Probe Lead Connections
The probe leads are color-coded and are inserted into the terminal block in the
following sequence:
Probe
1
1
1
2
2
2
3
3
3
RTV Seal
Tank Wall
Figure 3.8: Magnetic Mount, Application of RTV
Table 3.1: Probe Lead Connections
Panel Marking
COM
TMP
REF
COM
TMP
REF
COM
TMP
REF
16
Wire Color
Terminal #
White
Red
Black
White
Red
Black
White
Red
Black
Mount,
12
11
10
9
8
7
6
5
4
V6.70 20131017
