window multiple times will decrease the ratio. For instance, if the secondary
current maximum is 1.5 amperes, two more turns will give 4.5 amperes
effectively.
Figure 3.12 a & b illustrates the Auxiliary CT connections.
Figure 3.12a: NEMA CT
Connections
Figure 3.12b: Panel CT
Connections
WARNING!:
1. AUX CT P/N 56083213020 MUST BE USED, SEVERE DAMAGE WILL
RESULT IF THE SECONDARY LEADS OF THE BUSHING CT ARE
CONNECTED DIRECTLY TO THE UNIT.
2. THE SHIELD DRAIN WIRE FROM THE AUX CT P/N 56083213020 MUST
BE CONNECTED TO THE TTC-1000 ENCLOSURE. SEE SECTION 3.10 FOR
SHIELD DRAIN GROUNDING.
