Advanced Power technologies TTC-1000 Instruction & Operation Manual page 60

Press the YES button. The first character will flash. Use the
to scroll between LEVEL and PULSE. Press YES when you have made the
correct selection.
For programming from a PC just type the input detection, IN1 through IN14
CNTRL, mode on the "Enter:" line as follows:
This will program the IN1 CNTRL to PULSE MODE. Type 01/0 for LEVEL
MODE.
The user has the ability to invert an input. When inverted, a wetted input will de-
assert. Conversely, an inverted input that does not have wetting voltage will be
asserted. When not inverted, the input must be wetted to be asserted.
To set from the front panel, press the
setting for desired input is displayed:
Press the YES button. The first character will flash. Use the
to scroll between NONINVERT and INVERT. Press YES when you have made
the correct selection.
For programming from a PC just type the input detection, IN1 through IN14
NONINVERT/INVERT on the "Enter:" line as follows:
This will program the IN1 from NONINVERT to INVERT. Type 59/0 for
NONINVERT.
PRGM SETTING 045
I N 1 C N T R L = L E V E L
Enter:45/1

PRGM SETTING 059
I N 1 = N O N I N V E R T
Enter:59/1
51


or arrow button until the inversion


or arrow buttons

or arrow buttons
