Advanced Power technologies TTC-1000 Instruction & Operation Manual page 166

Setting # Setting
(!) SP31 (*/+)
105
TO OUTn
(!) SP32 (*/+)
106
TO OUTn
(!) SP33 (*/+)
107
TO OUTn
(!) SP34 (*/+)
108
TO OUTn
(!) LTCDIFF1
109
(*/+) TO OUTn
Purpose
Programmable logic
for SP31
DO NOT USE FOR
SINGLE PROBE
Programmable logic
for SP32
DO NOT USE FOR
SINGLE PROBE
Programmable logic
for SP33
DO NOT USE FOR
SINGLE PROBE
Programmable logic
for SP34
DO NOT USE FOR
SINGLE PROBE
Programmable logic
for LTCDIFF1
DO NOT USE FOR
SINGLE PROBE
157
Setting Range or Values
105/0/0/0: SP31 not assigned
105/0/0/n: SP31 * to OUTn
105/1/0/n: !SP31 * to OUTn
105/0/1/n: SP31 + to OUTn
105/1/1/n: !SP31 + to OUTn
where n=1,2,3,4,5,6
106/0/0/0: SP32 not assigned
106/0/0/n: SP32 * to OUTn
106/1/0/n: !SP32 * to OUTn
106/0/1/n: SP32 + to OUTn
106/1/1/n: !SP32 + to OUTn
where n=1,2,3,4,5,6
107/0/0/0: SP33 not assigned
107/0/0/n: SP33 * to OUTn
107/1/0/n: !SP33 * to OUTn
107/0/1/n: SP33 + to OUTn
107/1/1/n: !SP33 + to OUTn
where n=1,2,3,4,5,6
108/0/0/0: SP34 not assigned
108/0/0/n: SP34 * to OUTn
108/1/0/n: !SP34 * to OUTn
108/0/1/n: SP34 + to OUTn
108/1/1/n: !SP34 + to OUTn
where n=1,2,3,4,5,6
109/0/0/0: LTCDIFF1 not
assigned
109/0/0/n: LTCDIFF1 * to
OUTn
109/1/0/n: !LTCDIFF1 * to
OUTn
109/0/1/n: LTCDIFF1 + to
OUTn
109/1/1/n: !LTCDIFF1 + to
OUTn
where n=1,2,3,4,5,6
Program to
V6.70 20131017
