Advanced Power technologies TTC-1000 Instruction & Operation Manual page 162

Setting # Setting
OUT1 xxxxx (n)
76
w/ALRM
OUT2 PICKUP
77
TMR
OUT2 TMR
78
CNTRL
OUT2
79
AUTO/MANUAL
OUT2 xxxxx (n)
80
w/ALRM
OUT3 PICKUP
81
TMR
OUT3 TMR
82
CNTRL
OUT3
83
AUTO/MANUAL
Purpose
Controls Behavior of
output when Device
or Temp Alarm
Delays activation of
an output
Sets if output timer
is a delay on pickup
or a non-
retriggerable one-
shot
Operate Output in
AUTO or MANUAL
control
Controls Behavior of
output when Device
or Temp Alarm
Delays activation of
an output
Sets if output timer
is a delay on pickup
or a non-
retriggerable one-
shot
Operate Output in
AUTO or MANUAL
control
153
Setting Range or Values
76/0: OUT1 UNCHG (0)
w/ALRM
76/1: OUT1 PCKUP (1)
w/ALRM
76/2: OUT1 SUPVS (2)
w/ALRM
76/3: OUT1 NOACT (3)
w/ALRM
77/nnn
where n=0 to 255 seconds
78/0: OUT2 Delay on PICKUP
(0)
78/1: OUT2 PULSE (1)
79/0: AUTO (uses
programmable logic
79/1: MANUAL (control
through front panel)
80/0: OUT2 UNCHG (0)
w/ALRM
80/1: OUT2 PCKUP (1)
w/ALRM
80/2: OUT2 SUPVS (2)
w/ALRM
80/3: OUT2 NOACT (3)
w/ALRM
81/nnn
where n=0 to 255 seconds
82/0: OUT3 Delay on PICKUP
(0)
82/1: OUT3 PULSE (1)
83/0: AUTO (uses
programmable logic
83/1: MANUAL (control
through front panel)
Program to
V6.70 20131017
