Advanced Power technologies TTC-1000 Instruction & Operation Manual page 174

Setting # Setting
161 BAUD RATE
162 NODE ADDR
163 REMOTE BLK
164 TIMEBASE
INCLUDE P1
165
IN LOG
INCLUDE P2
166
IN LOG
INCLUDE P3
167
IN LOG
INCLUDE
168 WINDING1 IN
LOG
INCLUDE
LOAD1
169
IN LOG
170 TIME
171 DATE
172 WNDCKT ALRM
173 DEVICE ALRM
Purpose
Sets baud rate for
RS-485 interface
Sets the node
address for DNP3.0
or MODBUS
communications
Enables blocking of
remote control
commands through
DNP3.0 or
MODBUS
Sets record time for
data log
Sets P1 for data log
Sets P2 for data log
Sets P3 for data log
Sets Calculated
Winding Temp. for
data log
Sets LOAD for data
log
Sets time of day
Sets date
Enables or disables
winding circuit alarm
Enables or disables
device alarm
165
Setting Range or Values
161/0: 1200 baud
161/1: 2400 baud
161/2: 9600 baud
161/3: 19200 baud
162/xxxxx
where xxxxx=0 to 65535
163/0: Disables remote block
163/1: Enables remote block
164/nnnn
where nnnn=0 to 9999
165/0: NO
165/1: YES
166/0: NO
166/1: YES
167/0: NO
167/1: YES
168/0: NO
168/1: YES
SET ONLY IF Aux CT avail.
169/0: NO
169/1: YES
SET ONLY IF Aux CT avail.
170/xx:xx
where xx:xx= 00:00 to 23:59
171/mm/dd/yr
where mm=01-12
dd=01-31
yr=00 to 99
172/0: Enabled
172/1: Disabled
173/0: Enabled
173/1: Disabled
Program to
V6.70 20131017
