Advanced Power technologies TTC-1000 Instruction & Operation Manual page 164

Setting # Setting
OUT5 xxxxx (n)
92
w/ALRM
OUT6 PICKUP
93
TMR
OUT6 TMR
94
CNTRL
OUT6
95
AUTO/MANUAL
OUT6 xxxxx (n)
96
w/ALRM
(!) SP11 (*/+)
97
TO OUTn
(!) SP12 (*/+)
98
TO OUTn
Purpose
Controls Behavior of
output when Device
or Temp Alarm
Delays activation of
an output
Sets if output timer
is a delay on pickup
or a non-
retriggerable one-
shot
Operate Output in
AUTO or MANUAL
control
Controls Behavior of
output when Device
or Temp Alarm
Programmable logic
for SP11
Programmable logic
for SP12
155
Setting Range or Values
92/0: OUT5 UNCHG (0)
w/ALRM
92/1: OUT5 PCKUP (1)
w/ALRM
92/2: OUT5 SUPVS (2)
w/ALRM
92/3: OUT5 NOACT (3)
w/ALRM
93/nnn
where n=0 to 255 seconds
94/0: OUT6 Delay on PICKUP
(0)
94/1: OUT6 PULSE (1)
95/0: AUTO (uses
programmable logic
95/1: MANUAL (control
through front panel)
96/0: OUT6 UNCHG (0)
w/ALRM
96/1: OUT6 PCKUP (1)
w/ALRM
96/2: OUT6 SUPVS (2)
w/ALRM
96/3: OUT6 NOACT (3)
w/ALRM
97/0/0/0: SP11 not assigned
97/0/0/n: SP11 * to OUTn
97/1/0/n: !SP11 * to OUTn
97/0/1/n: SP11 + to OUTn
97/1/1/n: !SP11 + to OUTn
where n=1,2,3,4,5,6
98/0/0/0: SP12 not assigned
98/0/0/n: SP12 * to OUTn
98/1/0/n: !SP12 * to OUTn
98/0/1/n: SP12 + to OUTn
98/1/1/n: !SP12 + to OUTn
where n=1,2,3,4,5,6
Program to
V6.70 20131017
