Advanced Power technologies TTC-1000 Instruction & Operation Manual page 145

Setting # Setting
(!) SP33 (*/+) TO
OUTn
107
(Not functional in
single probe units)
(!) SP34 (*/+) TO
OUTn
108
(Not functional in
single probe units)
(!) LTC1 (*/+) TO
OUTn
109
(Not functional in
single probe units)
(!) LTC2 (*/+) TO
OUTn
110
(Not functional in
single probe units)
(!) R-R1 (*/+) TO
111
OUTn
(!) R-R2 (*/+) TO
112
OUTn
Purpose
Assigns probe #3 set
point to a specific output
using a defined AND or
OR logic operator
Assigns probe #3 set
point to a specific output
using a defined AND or
OR logic operator
Assigns the LTC1
differential SP to a
specific output using a
defined AND or OR logic
operator
Assigns the LTC2
differential SP to a
specific output using a
defined AND or OR logic
operator
Assigns an output to a
specific output using a
defined AND or OR logic
operator
Assigns an output to a
specific output using a
defined AND or OR logic
operator
136
Setting Range or
Values
SP33 * OUT n
! SP33 * OUT n
SP33 + OUT n
! SP33 + OUT n
where n=1,2,3,4,5,6
SP34 * OUT n
! SP34 * OUT n
SP34 + OUT n
! SP34 + OUT n
where n=1,2,3,4,5,6
LTC1 * OUT n
! LTC1 * OUT n
LTC1 + OUT n
! LTC1 + OUT n
where n=1,2,3,4,5,6
LTC2 * OUT n
! LTC2 * OUT n
LTC2 + OUT n
! LTC2 + OUT n
where n=1,2,3,4,5,6
R-R1 * OUT n
! R-R1 * OUT n
R-R1 + OUT n
! R-R1 + OUT n
where n=1,2,3,4,5,6
R-R2 * OUT n
! R-R2 * OUT n
R-R2 + OUT n
! R-R2 + OUT n
where n=1,2,3,4,5,6
Factory
Program to
Default
SP33 *
OUT0
SP34 *
OUT0
LTC1 *
OUT0
LTC2 *
OUT0
R-R1 *
OUT0
R-R2 *
OUT0
