Advanced Power technologies TTC-1000 Instruction & Operation Manual page 140

Setting # Setting
IN13=NONINVERT
or INVERT
(functional only in
071
units equipped with
optically isolated
inputs)
IN14=NONINVERT
or INVERT
(functional only in
072
units equipped with
optically isolated
inputs)
073 OUT1PUTMR
074 OUT1TMRCTL
075 OUT1CTRL
OUT1(Action)
w/ALRM
076
Action: UNCHG,
PCKUP,SUPV,
NOACT
077 OUT2PUTMR
078 OUT2TMRCTL
079 OUT2CTRL
Purpose
Changes if input picks
up when energized
(NONIVERT) or when
de-energized (INVERT)
Changes if input picks
up when energized
(NONIVERT) or when
de-energized (INVERT)
Delays activation of an
output
Defines output timer to
either delay on pickup or
pulse mode
Permits manual control
of OUT1
Allows OUT1 to default
when a DEVICE or
TPROBE alarm
Delays activation of an
output
Defines output timer to
either delay on pickup or
pulse mode
Permits manual control
of OUT2
131
Setting Range or
Values
NONINVERT or
INVERT
NONINVERT or
INVERT
0 to 255 seconds (Note:
a 0 setting results in a
32msec delay)
DELAY or PULSE
AUTO, MAN OFF, MAN
ON
OUT1UNCHGw/ALRM
does not allow OUT1 to
change state when
alarm
OUT1PCKUPw/ALRM
causes OUT1 to pickup
when alarm
OUT1SUPVw/ALRM
drops out OUT1 when
alarm
OUT1NOACTw/ALRM
prevents output logic
from being processed
0 to 255 seconds (Note:
a 0 setting results in a
32msec delay)
DELAY or PULSE
AUTO, MAN OFF, MAN
ON
Factory
Program to
Default
NONINV
ERT
NONINV
ERT
0
DELAY
AUTO
OUT1
UNCHG
w/ALRM
0
DELAY
AUTO
V6.70 20131017
