Advanced Power technologies TTC-1000 Instruction & Operation Manual page 144

Setting # Setting
(!) SP21 (*/+) TO
OUTn
101
(Not functional in
single probe units)
(!) SP22 (*/+) TO
OUTn
102
(Not functional in
single probe units)
(!) SP23 (*/+) TO
OUTn
103
(Not functional in
single probe units)
(!) SP24 (*/+) TO
OUTn
104
(Not functional in
single probe units)
(!) SP31 (*/+) TO
OUTn
105
(Not functional in
single probe units)
(!) SP32 (*/+) TO
OUTn
106
(Not functional in
single probe units)
Purpose
Assigns probe #2 set
point to a specific output
using a defined AND or
OR logic operator
Assigns probe #2 set
point to a specific output
using a defined AND or
OR logic operator
Assigns probe #2 set
point to a specific output
using a defined AND or
OR logic operator
Assigns probe #2 set
point to a specific output
using a defined AND or
OR logic operator
Assigns probe #3 set
point to a specific output
using a defined AND or
OR logic operator
Assigns probe #3 set
point to a specific output
using a defined AND or
OR logic operator
135
Setting Range or
Values
SP21 * OUT n
! SP21 * OUT n
SP21 + OUT n
! SP21 + OUT n
where n=1,2,3,4,5,6
SP22 * OUT n
! SP22 * OUT n
SP22 + OUT n
! SP22 + OUT n
where n=1,2,3,4,5,6
SP23 * OUT n
! SP23 * OUT n
SP23 + OUT n
! SP23 + OUT n
where n=1,2,3,4,5,6
SP24 * OUT n
! SP24 * OUT n
SP24 + OUT n
! SP24 + OUT n
where n=1,2,3,4,5,6
SP31 * OUT n
! SP31 * OUT n
SP31 + OUT n
! SP31 + OUT n
where n=1,2,3,4,5,6
SP32 * OUT n
! SP32 * OUT n
SP32 + OUT n
! SP32 + OUT n
where n=1,2,3,4,5,6
Factory
Program to
Default
SP21 *
OUT0
SP22 *
OUT0
SP23 *
OUT0
SP24 *
OUT0
SP31 *
OUT0
SP32 *
OUT0
V6.70 20131017
