A mounting bracket, P/N: 80001000167, suitable for retrofit or new applications is
shown in Figure 3.2. The bracket is constructed from 1/8" THK 5052 Aluminum.
1.000
Ø 0.312
2.122
4 PLACES
0.000
16.500
15.875
15.127
13.252
Ø 0.516
6 PLACES
9.500
8.500
7.500
6.750
4.875
0.625
0.000

Figure 3.2: Mounting Bracket

3.2 Power Hookup

The TTC-1000 can be powered from either DC substation battery between
voltages of 38 to 160 VDC or from AC voltage of 120 ±10% VAC. Power is
connected to terminals 1 and 2 on TB-3. The TTC-1000 is not sensitive to
TB5
A1
+
N C N N C
C O C
OUT 3 OUT 2
Rx
Tx
Rpt
TB3
Tx
AUX CT

Figure 3.3b: Panel Power Connections

9.250
7.122
8.250
R 0.375
4 PLACES
0.000
polarity because it uses a bridge rectifier on
the power input. This feature eliminates the
risk of damage due to the reversal of power
applied to this input.
A2 A3
+ +
- - -
N N C N
O C O
GROUND
OUT1
ALARM POWER

Figure 3.3a: NEMA Power Connections

45
2 PLACES
2.000
TB2
TB1A
12
Aux CT Power
4 3 2 1
TB3
TB1
V6.70 20131017
