Advanced Power technologies TTC-1000 Instruction & Operation Manual page 159

Setting # Setting
51 IN7 CTRL
52 IN8 CTRL
53 IN9 CTRL
54 IN10 CTRL
55 IN11 CTRL
56 IN12 CTRL
57 IN13 CTRL
58 IN14 CTRL
IN1
59 NONINVERT or
INVERT
Purpose
Allows the input to
handle pulses
Allows the input to
handle pulses
Allows the input to
handle pulses
Allows the input to
handle pulses
Allows the input to
handle pulses
Allows the input to
handle pulses
Allows the input to
handle pulses
Allows the input to
handle pulses
Sets if input is
picked up
(NONINVERT) or
dropped out
(INVERT) when
energized
150
Setting Range or Values
51/0: LEVEL
51/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
52/0: LEVEL
52/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
53/0: LEVEL
53/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
54/0: LEVEL
54/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
55/0: LEVEL
55/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
56/0: LEVEL
56/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
57/0: LEVEL
57/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
58/0: LEVEL
58/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
59/0: NONINVERT
59/1: INVERT
SET ONLY IF Optically
Isolated Inputs avail.
Program to
V6.70 20131017
