Advanced Power technologies TTC-1000 Instruction & Operation Manual page 147

Setting # Setting
(!) OUT1 (*/+) TO
119
OUTn
(!) OUT2 (*/+) TO
120
OUTn
(!) OUT3 (*/+) TO
121
OUTn
(!) OUT4 (*/+) TO
122
OUTn
(!) OUT5(*/+) TO
123
OUTn
(!) OUT6 (*/+) TO
124
OUTn
Purpose
Assigns an output to a
specific output using a
defined AND or OR logic
operator
Assigns an output to a
specific output using a
defined AND or OR logic
operator
Assigns an output to a
specific output using a
defined AND or OR logic
operator
Assigns an output to a
specific output using a
defined AND or OR logic
operator
Assigns an output to a
specific output using a
defined AND or OR logic
operator
Assigns an output to a
specific output using a
defined AND or OR logic
operator
138
Setting Range or
Values
OUT1 * OUT n
! OUT1 * OUT n
OUT1 + OUT n
! OUT1 + OUT n
where n=1,2,3,4,5,6
OUT2 * OUT n
! OUT2 * OUT n
OUT2 + OUT n
! OUT2 + OUT n
where n=1,2,3,4,5,6
OUT3 * OUT n
! OUT3 * OUT n
OUT3 + OUT n
! OUT3 + OUT n
where n=1,2,3,4,5,6
OUT4 * OUT n
! OUT4 * OUT n
OUT4 + OUT n
! OUT4 + OUT n
where n=1,2,3,4,5,6
OUT5 * OUT n
! OUT5 * OUT n
OUT5 + OUT n
! OUT5 + OUT n
where n=1,2,3,4,5,6
OUT6 * OUT n
! OUT6 * OUT n
OUT6 + OUT n
! OUT6 + OUT n
where n=1,2,3,4,5,6
Factory
Program to
Default
OUT1 *
OUT0
OUT2 *
OUT0
OUT3 *
OUT0
OUT4 *
OUT0
OUT5*
OUT0
OUT6
OUT0
