Advanced Power technologies TTC-1000 Instruction & Operation Manual page 168

Setting # Setting
(!) WSP3 (*/+)
115
TO OUTn
(!) WSP4 (*/+)
116
TO OUTn
(!) LSP1 (*/+)
TO OUTn
117
(!) LSP2 (*/+)
TO OUTn
118
(!) OUT1 (*/+)
119
TO OUTn
(!) OUT2 (*/+)
120
TO OUTn
Purpose
Programmable logic
for WSP3
SET ONLY IF Aux
CT avail.
Programmable logic
for WSP4
SET ONLY IF Aux
CT avail.
Programmable logic
for LSP1
SET ONLY IF Aux
CT avail.
Programmable logic
for LSP2
SET ONLY IF Aux
CT avail.
Programmable logic
for OUT1
Programmable logic
for OUT2
159
Setting Range or Values
115/0/0/0: WSP3 not assigned
115/0/0/n: WSP3 * to OUTn
115/1/0/n: !WSP3 * to OUTn
115/0/1/n: WSP3 + to OUTn
115/1/1/n: !WSP3 + to OUTn
where n=1,2,3,4,5,6
116/0/0/0: WSP4 not assigned
116/0/0/n: WSP4 * to OUTn
116/1/0/n: !WSP4 * to OUTn
116/0/1/n: WSP4 + to OUTn
116/1/1/n: !WSP4 + to OUTn
where n=1,2,3,4,5,6
117/0/0/0: LSP1 not assigned
117/0/0/n: LSP1 * to OUTn
117/1/0/n: !LSP1 * to OUTn
117/0/1/n: LSP1 + to OUTn
117/1/1/n: !LSP1 + to OUTn
where n=1,2,3,4,5,6
118/0/0/0: LSP2 not assigned
118/0/0/n: LSP2 * to OUTn
118/1/0/n: !LSP2 * to OUTn
118/0/1/n: LSP2 + to OUTn
118/1/1/n: !LSP2 + to OUTn
where n=1,2,3,4,5,6
119/0/0/0: OUT1 not assigned
119/0/0/n: OUT1 * to OUTn
119/1/0/n: !OUT1 * to OUTn
119/0/1/n: OUT1 + to OUTn
119/1/1/n: !OUT1 + to OUTn
where n=1,2,3,4,5,6
120/0/0/0: OUT2 not assigned
120/0/0/n: OUT2 * to OUTn
120/1/0/n: !OUT2 * to OUTn
120/0/1/n: OUT2 + to OUTn
120/0/1/n: !OUT2 + to OUTn
where n=1,2,3,4,5,6
Program to
V6.70 20131017
