Advanced Power technologies TTC-1000 Instruction & Operation Manual page 142

Setting # Setting
OUT4 (Action)
w/ALRM
088
Action: UNCHG,
PCKUP, SUPV,
NOACT
089 OUT5PUTMR
090 OUT5TMRCTL
091 OUT5CTRL
OUT5(Action)
w/ALRM
092
Action: UNCHG,
PCKUP, SUPV,
NOACT
093 OUT6PUTMR
094 OUT6TMRCTL
095 OUT6CTRL
Purpose
Allows OUT4 default
when a DEVICE or
TPROBE alarm
Delays activation of an
output
Defines output timer to
either delay on pickup or
pulse mode
Permits manual control
of OUT5
Allows OUT5 default
when a DEVICE or
TPROBE alarm
Delays activation of an
output
Defines output timer to
either delay on pickup or
pulse mode
Permits manual control
of OUT6
133
Setting Range or
Values
OUT4UNCHGw/ALRM
does not allow OUT4 to
change state when
alarm
OUT4PCKUPw/ALRM
causes OUT4 to pickup
when alarm
OUT4SUPVw/ALRM
drops out OUT4 when
alarm
OUT4NOACTw/ALRM
prevents output logic
from being processed
0 to 255 seconds (Note:
a 0 setting results in
a 32msec delay)
DELAY or PULSE
AUTO, MAN OFF, MAN
ON
OUT5UNCHGw/ALRM
does not allow OUT5 to
change state when
alarm
OUT5PCKUPw/ALRM
causes OUT5 to pickup
when alarm
OUT5SUPVw/ALRM
drops out OUT5 when
alarm
OUT5NOACTw/ALRM
prevents output logic
from being processed
0 to 255 seconds (Note:
a 0 setting results in
a 32msec delay)
DELAY or PULSE
AUTO, MAN OFF, MAN
ON
Factory
Program to
Default
OUT4
UNCHG
w/ALRM
0
DELAY
AUTO
OUT5
UNCHG
w/ALRM
0
DELAY
AUTO
V6.70 20131017
