Advanced Power technologies TTC-1000 Instruction & Operation Manual page 185

Input
Discrete 16
Input
Discrete 17
Input
Discrete 18
Input
Discrete 19
Input
Discrete 20
Input
Discrete 21
Input
Discrete 22
Input
Discrete 23
Input
Discrete 24
Input
Discrete 25
Input
Discrete 26
Input
Discrete 27
Input
Discrete 28
Input
Discrete 29
Input
Discrete 30
Input
Discrete 31
Input
Discrete 32
Input
Out, 1-Picked Up
State of Set Point WSP21 (Winding 2, Set Point 1), 0-Dropped
Out, 1-Picked Up
State of Set Point WSP22 (Winding 2, Set Point 2), 0-Dropped
Out, 1-Picked Up
State of Set Point WSP23 (Winding 2, Set Point 3), 0-Dropped
Out, 1-Picked Up
State of Set Point WSP24 (Winding 2, Set Point 4), 0-Dropped
Out, 1-Picked Up
State of Set Point WSP31 (Winding 3, Set Point 1), 0-Dropped
Out, 1-Picked Up
State of Set Point WSP32 (Winding 3, Set Point 2), 0-Dropped
Out, 1-Picked Up
State of Set Point WSP33 (Winding 3, Set Point 3), 0-Dropped
Out, 1-Picked Up
State of Set Point WSP34 (Winding 3, Set Point 4), 0-Dropped
Out, 1-Picked Up
State of Set Point LSP11 (Load 1, Set Point 1), 0-Dropped Out,
1-Picked Up
State of Set Point LSP12 (Load 1, Set Point 2), 0-Dropped Out,
1-Picked Up
State of Set Point LSP21 (Load 2, Set Point 1), 0-Dropped Out,
1-Picked Up
State of Set Point LSP22 (Load 2, Set Point 2), 0-Dropped Out,
1-Picked Up
State of Set Point LSP31 (Load 3, Set Point 1), 0-Dropped Out,
1-Picked Up
State of Set Point LSP32 (Load 3, Set Point 2), 0-Dropped Out,
1-Picked Up
State of Set Point LSP41 (Load 4, Set Point 1), 0-Dropped Out,
1-Picked Up
State of Set Point LSP42 (Load 4, Set Point 2), 0-Dropped Out,
1-Picked Up
State of Set Point LSP51 (Load 5, Set Point 1), 0-Dropped Out,
1-Picked Up
176 V6.70 20131017
