Advanced Power technologies TTC-1000 Instruction & Operation Manual page 172

Setting # Setting
TIME1 xx:xx TO
139 yy:yy Assigned
TO OUTn
TIME2 xx:xx TO
140 yy:yy Assigned
TO OUTn
TIME3 xx:xx TO
141 yy:yy Assigned
TO OUTn
142 OUT1 INVERT
143 OUT2 INVERT
144 OUT3 INVERT
145 OUT4 INVERT
146 OUT5 INVERT
147 OUT6 INVERT
148 CT RATIO
149 RATED LOAD
WINDING RISE
150 @ RATED
LOAD
151 WINDING TC
COOLING
152
TYPE
Purpose
Assigns TIME1
setpoint to OUTn
Assigns TIME2
setpoint to OUTn
Assigns TIME3
setpoint to OUTn
Inverts OUT1
Inverts OUT2
Inverts OUT3
Inverts OUT4
Inverts OUT5
Inverts OUT6
Sets ratio of primary
CT
Sets rated load in
amps based on
mfg's data
Sets hotspot rise in
C over top oil at
rated load based on
mfg's data
Sets winding time
constant in minutes
based on mfg's data
Sets cooling type
163
Setting Range or Values
139/xx:xx/yy:yy/n
where xx:xx= pickup time
yy:yy=dropout time
n=0,1,2,3,4,5,6
140/xx:xx/yy:yy/n
where xx:xx= pickup time
yy:yy=dropout time
n=0,1,2,3,4,5,6
141/xx:xx/yy:yy/n
where xx:xx= pickup time
yy:yy=dropout time
n=0,1,2,3,4,5,6
142/0: Not INVERT
142/1: INVERT
143/0: Not INVERT
143/1: INVERT
144/0: Not INVERT
144/1: INVERT
145/0: Not INVERT
145/1: INVERT
146/0: Not INVERT
146/1: INVERT
147/0: Not INVERT
147/1: INVERT
148/nnnn
where nnnn= 0 to 6000
149/nnnnn
where nnnnn=0 to 65535
150/nn
where nn=0 to 99
151/nnn
where nnn=0 to 999
152/0: Not directed FOA/FOW
152/1: Directed FOA/FOW
Program to
V6.70 20131017
