Advanced Power technologies TTC-1000 Instruction & Operation Manual page 170

Setting # Setting
(!) IN3 (*/+) TO
127
OUTn
(!) IN4 (*/+) TO
128
OUTn
(!) IN5 (*/+) TO
129
OUTn
(!) IN6 (*/+) TO
130
OUTn
(!) IN7 (*/+) TO
131
OUTn
(!) IN8 (*/+) TO
132
OUTn
Purpose
Programmable logic
for IN3
SET ONLY IF
Optically Isolated
Input avail.
Programmable logic
for IN4
SET ONLY IF
Optically Isolated
Input avail.
Programmable logic
for IN5
SET ONLY IF
Optically Isolated
Input avail.
Programmable logic
for IN6
SET ONLY IF
Optically Isolated
Input avail.
Programmable logic
for IN7
SET ONLY IF
Optically Isolated
Input avail.
Programmable logic
for IN8
SET ONLY IF
Optically Isolated
Input avail.
161
Setting Range or Values
127/0/0/0: IN3 not assigned
127/0/0/n: IN3 * to OUTn
127/1/0/n: !IN3 * to OUTn
127/0/1/n: IN3 + to OUTn
127/1/1/n: !IN3 + to OUTn
where n=1,2,3,4,5,6
128/0/0/0: IN4 not assigned
128/0/0/n: IN4 * to OUTn
128/1/0/n: !IN4 * to OUTn
128/0/1/n: IN4 + to OUTn
128/1/1/n: !IN4 + to OUTn
where n=1,2,3,4,5,6
129/0/0/0: IN5 not assigned
129/0/0/n: IN5 * to OUTn
129/1/0/n: !IN5 * to OUTn
129/0/1/n: IN5 + to OUTn
129/1/1/n: !IN5 + to OUTn
where n=1,2,3,4,5,6
130/0/0/0: IN6 not assigned
130/0/0/n: IN6 * to OUTn
130/1/0/n: !IN6 * to OUTn
130/0/1/n: IN6 + to OUTn
130/1/1/n: !IN6 + to OUTn
where n=1,2,3,4,5,6
131/0/0/0: IN7 not assigned
131/0/0/n: IN7 * to OUTn
131/1/0/n: !IN7 * to OUTn
131/0/1/n: IN7 + to OUTn
131/1/1/n: !IN7 + to OUTn
where n=1,2,3,4,5,6
132/0/0/0: IN8 not assigned
132/0/0/n: IN8 * to OUTn
132/1/0/n: !IN8 * to OUTn
132/0/1/n: IN8 + to OUTn
132/1/1/n: !IN8 + to OUTn
where n=1,2,3,4,5,6
Program to
V6.70 20131017
