Advanced Power technologies TTC-1000 Instruction & Operation Manual page 151

Setting # Setting
DIRECTED FOA
(functional only in
152
units equipped with
CT)
153 P1 NAME
154 P2 NAME
155 P3 NAME
156 ALTERNATE
157 ANALGOUT
158 A1 SOURCE
159 A2 SOURCE
160 A3 SOURCE
161 BAUD RATE
162 NODE ADDR
163 REMOTE BLK
164 TIMEBASE
165 P1 RECORD
166 P2 RECORD
Purpose
Sets cooling type to
direct FOA/FOW
Probe #1 name
Probe #2 name
(optional)
Probe #3 name
(optional)
Selects an output pair to
alternate between to
exercise fans
Current loop current
range
Sets source for analog
output A1
Sets source for analog
output A2
Sets source for analog
output A3
Sets baud rate for RS-
485 interface
Sets the node address
for DNP3.0 or MODBUS
Blocks remote control
command
Sets record time for data
log
Sets P1 for data log
Sets P2 for data log
142
Setting Range or
Values
YES, NO
0. TOP OIL
1. WINDING
2. AMBIENT
3. LTC DIFF
4. BOTTOM OIL
5. TOP OIL 1
6. TOP OIL 2
7. TOP OIL 3
8. LTC DIFF1
9. LTCDIFF2
10. WINDING1
11. WINDING2
12. WINDING3
13. LV WINDING
14. HV WINDING
15. TERTIARY
WINDING
16. LTC TANK
17. DIVERTER TANK
18. SELECTOR TANK
19. NONE
DSABL, 1-2, 1-3, 1-4,
2-3, 2-4, 3-4
0to1mA or 4to20mA
0. P1 (probe #1)
1. P2 (probe #2)
2. P3 (Probe #3)
3. WINDING1 (Calc)
1200, 2400, 9600,
19200
0 – 65535
ENABL to block remote
control or DSABL to
allow remote control
0 - 9999
YES, NO
YES, NO
Factory
Program to
Default
NO
TOP OIL
TOP OIL
(only in
dual
probe)
TOP OIL
(only in
triple
probe)
DSABL
0to1mA
P1
P1
P1
1200
0
DSBL
0
NO
NO
V6.70 20131017
