Advanced Power technologies TTC-1000 Instruction & Operation Manual page 146

Setting # Setting
(!) WSP1 (*/+) TO
OUTn
(functional only in
113
units equipped with
aux CT)
(!) WSP2 (*/+) TO
OUTn
114
(functional only in
units equipped with
aux CT)
(!) WSP3 (*/+) TO
OUTn
115
(functional only in
units equipped with
aux CT)
(!) WSP4 (*/+) TO
OUTn
116
(functional only in
units equipped with
aux CT)
(!) LSP1 (*/+) TO
OUTn
117
(functional only in
units equipped with
aux CT)
(!) LSP2 (*/+) TO
OUTn
118
(functional only in
units equipped with
aux CT)
Purpose
Assigns calculated
winding set points to a
specific output using a
defined AND or OR logic
operator
Assigns calculated
winding set points to a
specific output using a
defined AND or OR logic
operator
Assigns calculated
winding set points to a
specific output using a
defined AND or OR logic
operator
Assigns calculated
winding set points to a
specific output using a
defined AND or OR logic
operator
Assigns load set points
to a specific output using
a defined AND or OR
logic operator
Assigns load set points
to a specific output using
a defined AND or OR
logic operator
137
Setting Range or
Values
WSP1 * OUT n
! WSP1 * OUT n
WSP1 + OUT n
! WSP1 + OUT n
where n=1,2,3,4,5,6
WSP2 * OUT n
! WSP2 * OUT n
WSP2 + OUT n
! WSP2 + OUT n
where n=1,2,3,4,5,6
WSP3 * OUT n
! WSP3 * OUT n
WSP3 + OUT n
! WSP3 + OUT n
where n=1,2,3,4,5,6
WSP4 * OUT n
! WSP4 * OUT n
WSP4 + OUT n
! WSP4 + OUT n
where n=1,2,3,4,5,6
LSP1 * OUT n
! LSP1 * OUT n
LSP1 + OUT n
! LSP1 + OUT n
where n=1,2,3,4,5,6
LSP2 * OUT n
! LSP2 * OUT n
LSP2 + OUT n
! LSP2 + OUT n
where n=1,2,3,4,5,6
Factory
Program to
Default
WSP1 *
OUT0
WSP2 *
OUT0
WSP3 *
OUT0
WSP4 *
OUT0
LSP1 *
OUT0
LSP2 *
OUT0
