Setting #
Setting
41
LSP2 PICKUP
42
LSP2 DRPOUT
LOAD PICKUP
43
TMR1
LOAD PICKUP
44
TMR2
45
IN1 CTRL
46
IN2 CTRL
47
IN3 CTRL
48
IN4 CTRL
49
IN5 CTRL
50
IN6 CTRL
Purpose
Load pickup current
Load dropout
current
Load pickup timer
for LSP1
Load pickup timer
for LSP2
Allows the input to
handle pulses
Allows the input to
handle pulses
Allows the input to
handle pulses
Allows the input to
handle pulses
Allows the input to
handle pulses
Allows the input to
handle pulses
149
Setting Range or Values
41/n.n
where n.n=0.0 to 9.9
SET ONLY IF Aux CT avail.
42/n.n
where n.n=0.0 to 9.9
SET ONLY IF Aux CT avail.
43/nnn
where n=0 to 255 seconds
SET ONLY IF Aux CT avail.
44/nnn
where n=0 to 255 seconds
SET ONLY IF Aux CT avail.
45/0: LEVEL
45/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
46/0: LEVEL
46/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
47/0: LEVEL
47/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
48/0: LEVEL
48/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
49/0: LEVEL
49/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
50/0: LEVEL
50/1: PULSE
SET ONLY IF Optically
Isolated Inputs avail.
Program to
V6.70 20131017
