1. Press Enter to display the TTC-1000 Main Menu
2. Type 6 followed by / followed by the 4 digit password:
a. Note that at any time the internal data in the unit is to be changed,
the password will need to be entered.
3. The screen will display the following message, which indicates that the
TTC-1000 is ready to accept the CSV settings file.
CSV FILE TRANSFER IN PROGRESS. PRESS Any KEY TO
ABORT". §§§§§§§§§§§§§§
4. Click on Transfer on the HyperAccess toolbar
a. A drop down menu will appear
b. Click on the Send File option
5. A dialog box will open to select the location and name of the file to be
transferred.
a. Click on Browse to select the directory and then the file to be sent.
b. Make sure Xmodem is selected in the Protocol window
c. Click on the Settings button to make sure the error checking is set
to Checksum
d. Click on the Send button.
6. A dialog box will appear to track the transfer progress.
7. The dialog box will disappear and a note will appear in the terminal
window that the transfer was successful.
NOTE: The TTC-1000 will suspend all measurements and calculations once
downloading is selected. The outputs will also be blocked during this time.
The TTC-1000 transfers the new settings to a buffer register and will
transfer the settings to E
2
memory only after the checksum test is passed.
