Setting # Setting
167 P3 RECORD
WNDG1RECORD
(functional only in
168
units equipped with
aux CT)
LOAD1RECORD
(functional only in
169
units equipped with
aux CT)
170 TIME
171 DATE
172 WNDCKTALARM
173 DEVICEALRM
174 TPROBEALRM
175 MANALRM
176 TIME SP CNTR
177 UNIT ID
178 NEG ANALGOUT
179 LTCDIFF1 RISE
180 LTCDIFF1 RATE
181 LTCDIFF2 RISE
182 LTCDIFF2 RATE
183 REPEAT
184 PASSWORD
Purpose
Sets P3 for data log
Sets Calculated Winding
Temperature for data log
Sets LOAD for data log
Sets military time
Sets date
Winding circuitry alarm
enable
Processor alarm enable
Temperature
measurement alarm
enable
Manual mode alarm
enable
Sets time counter for
Time Setpoints
operation
A six character name for
unit
Enables scaling of
analog outputs for
negative temperatures
Maximum LTCDIFF1
rise in time period
LTCDIFF1 RATE
Time period in which
LTCDIFF1 is examined
Maximum LTCDIFF2
rise in time period
LTCDIFF2 RATE
Time period in which
LTCDIFF2 is examined
Enables repeat mode for
fiber comm. channel
Allows access to
program mode
143
Setting Range or
Values
YES, NO
YES, NO
YES, NO
HH:MM
MM/DD/YY
ENABL for enabled or
DSABL for disabled
ENABL for enabled or
DSABL for disabled
ENABL for enabled or
DSABL for disabled
ENABL for enabled or
DSABL for disabled
0 to 255
Any six alphanumeric
characters
YES, NO
5 to 40 ºC
(recommended)
1 to 255 minutes
5 to 40 ºC
(recommended)
1 to 255 minutes
YES, NO
4 digits
Factory
Program to
Default
NO
NO
NO
00:00
00/00/00
ENABL
ENABL
ENABL
ENABL
0
Blank
NO
0
0
0
0
NO
0000
