Setting # Setting
OUT6(Action)
w/ALRM
096
Action: UNCHG,
PCKUP, SUPV,
NOACT
(!) SP11 (*/+) TO
097
OUTn
(!) SP12 (*/+) TO
098
OUTn
(!) SP13 (*/+) TO
099
OUTn
(!) SP14 (*/+) TO
100
OUTn
Purpose
Allows OUT6 default
when a DEVICE or
TPROBE alarm
Assigns probe #1 set
point to a specific output
using a defined AND or
OR logic operator
Assigns probe #1 set
point to a specific output
using a defined AND or
OR logic operator
Assigns probe #1 set
point to a specific output
using a defined AND or
OR logic operator
Assigns probe #1 set
point to a specific output
using a defined AND or
OR logic operator
134
Setting Range or
Values
OUT6UNCHGw/ALRM
does not allow OUT6 to
change state when
alarm
OUT6PCKUPw/ALRM
causes OUT6 to pickup
when alarm
OUT6SUPVw/ALRM
drops out OUT6 when
alarm
OUT6NOACTw/ALRM
prevents output logic
from being processed
SP11 * OUT n
! SP11 * OUT n
SP11 + OUT n
! SP11 + OUT n
where n=1,2,3,4,5,6
SP12 * OUT n
! SP12 * OUT n
SP12 + OUT n
! SP12 + OUT n
where n=1,2,3,4,5,6
SP13 * OUT n
! SP13 * OUT n
SP13 + OUT n
! SP13 + OUT n
where n=1,2,3,4,5,6
SP14 * OUT n
! SP14 * OUT n
SP14 + OUT n
! SP14 + OUT n
where n=1,2,3,4,5,6
Factory
Program to
Default
OUT6
UNCHG
w/ALRM
SP11 *
OUT0
SP12 *
OUT0
SP13 *
OUT0
SP14 *
OUT0
