Advanced Power technologies TTC-1000 Instruction & Operation Manual page 188

Discrete 69
Input
Discrete 70
Input
Discrete 71
Input
Discrete 72
Input
Discrete 73
Input
Discrete 74
Input
Coil 0
Coil 1
Coil 2
Coil 3
Coil 4
Coil 5
Coil 6
Coil 7
Input 0
Register
Input 1
Register
Input 2
Register
Input 3
Register
Input 4
Register
Input 5
Register
State of Optically Isolated Input, IN13, 0-Dropped Out, 1-Picked
Up
State of Optically Isolated Input, IN14, 0-Dropped Out, 1-Picked
Up
State of Device Alarm, 0-No Alarm, 1-Alarm
State of Temperature Probe Alarm, 0-No Alarm, 1-Alarm
State of Remote Block, 0-Remote Block Disabled, 1-Remote Block
Enabled
State of Winding Circuit Alarm, 0-No Alarm, 1-Alarm
OUT1 Control, 1-remote on, 0-local contro
OUT2 Control, 1-remote on, 0-local contro
OUT3 Control, 1-remote on, 0-local contro
OUT4 Control, 1-remote on, 0-local contro
OUT5 Control, 1-remote on, 0-local contro
OUT6 Control, 1-remote on, 0-local contro
OUT7 Control, 1-remote on, 0-local contro
OUT8 Control, 1-remote on, 0-local contro
Probe 1 Temperature (2's complement signed number, deg C)
Probe 2 Temperature
Probe 3 Temperature
Calculated Winding 1 Hotspot Temperature (2's complement signed
number, deg C)
Calculated Winding 2 Hotspot Temperature
Calculated Winding 3 Hotspot Temperature
179
l
l
l
l
l
l
l
l
V6.70 20131017
