Advanced Power technologies TTC-1000 Instruction & Operation Manual page 148

Setting # Setting
(!) IN1 (*/+) TO
OUTn
(functional only in
125
units equipped with
optically isolated
inputs)
(!) IN2 (*/+) TO
OUTn
(functional only in
126
units equipped with
optically isolated
inputs)
(!) IN3 (*/+) TO
OUTn
(functional only in
127
units equipped with
optically isolated
inputs)
(!) IN4 (*/+) TO
OUTn
(functional only in
128
units equipped with
optically isolated
inputs)
(!) IN5 (*/+) TO
OUTn
(functional only in
129
units equipped with
optically isolated
inputs)
(!) IN6 (*/+) TO
OUTn
(functional only in
130
units equipped with
optically isolated
inputs)
Purpose
Assigns optically
isolated input to a
specific output using a
defined AND or OR logic
operator
Assigns optically
isolated input to a
specific output using a
defined AND or OR logic
operator
Assigns optically
isolated input to a
specific output using a
defined AND or OR logic
operator
Assigns optically
isolated input to a
specific output using a
defined AND or OR logic
operator
Assigns optically
isolated input to a
specific output using a
defined AND or OR logic
operator
Assigns optically
isolated input to a
specific output using a
defined AND or OR logic
operator
139
Setting Range or
Values
IN1 * OUT n
! IN1 * OUT n
IN1 + OUT n
! IN1 + OUT n
where n=1,2,3,4,5,6
IN2 * OUT n
! IN2 * OUT n
IN2 + OUT n
! IN2 + OUT n
where n=1,2,3,4,5,6
IN3 * OUT n
! IN3 * OUT n
IN3 + OUT n
! IN3 + OUT n
where n=1,2,3,4,5,6
IN4 * OUT n
! IN4 * OUT n
IN4 + OUT n
! IN4 + OUT n
where n=1,2,3,4,5,6
IN5 * OUT n
! IN5 * OUT n
IN5 + OUT n
! IN5 + OUT n
where n=1,2,3,4,5,6
IN6 * OUT n
! IN6 * OUT n
IN6 + OUT n
! IN6 + OUT n
where n=1,2,3,4,5,6
Factory
Program to
Default
IN1 *
OUT0
IN2 *
OUT0
IN3 *
OUT0
IN4 *
OUT0
IN5 *
OUT0
IN6 *
OUT0
V6.70 20131017
