Advanced Power technologies TTC-1000 Instruction & Operation Manual page 141

Setting # Setting
OUT2 (Action)
w/ALRM
080
Action: UNCHG,
PCKUP, SUPV,
NOACT
081 OUT3PUTMR
082 OUT3TMRCTL
083 OUT3CTRL
OUT3(Action)
w/ALRM
084
Action: UNCHG,
PCKUP,SUPV,
NOACT
085 OUT4PUTMR
086 OUT4TMRCTL
087 OUT4CTRL
Purpose
Allows OUT2 to default
when a DEVICE or
TPROBE alarm
Delays activation of an
output
Defines output timer to
either delay on pickup or
pulse mode
Permits manual control
of OUT3
Allows OUT3 to default
when a DEVICE or
TPROBE alarm
Delays activation of an
output
Defines output timer to
either delay on pickup or
pulse mode
Permits manual control
of OUT4
132
Setting Range or
Values
OUT2UNCHGw/ALRM
does not allow OUT2 to
change state when
alarm
OUT2PCKUPw/ALRM
causes OUT2 to pickup
when alarm
OUT2SUPVw/ALRM
drops out OUT2 when
alarm
OUT2NOACTw/ALRM
prevents output logic
from being processed
0 to 255 seconds (Note:
a 0 setting results in a
32msec delay)
DELAY or PULSE
AUTO, MAN OFF, MAN
ON
OUT3UNCHGw/ALRM
does not allow OUT3 to
change state when
alarm
OUT3PCKUPw/ALRM
causes OUT3 to pickup
when alarm
OUT3SUPVw/ALRM
drops out OUT3 when
alarm
OUT3NOACTw/ALRM
prevents output logic
from being processed
0 to 255 seconds (Note:
a 0 setting results in
a 32msec delay)
DELAY or PULSE
AUTO, MAN OFF, MAN
ON
Factory
Program to
Default
OUT2
UNCHG
w/ALRM
0
DELAY
AUTO
OUT3
UNCHG
w/ALRM
0
DELAY
AUTO
