Boot Settings Configuration - Congatec COM Express conga-TR3 User Manual

11.4.2

Boot Settings Configuration

Feature
Quiet Boot
Setup Prompt Timeout
Bootup NumLock State
Enter Setup If No Boot Device
Enable Popup Boot Menu
Boot Priority Selection
Boot Option Sorting Method
1st, 2nd, 3rd, ...
Boot Device
(Up to 12 boot devices can be prioritized
if "UEFI Standard" priority list control is
selected. If "Type Based" priority list control
is enabled only 8 boot devices can be
prioritized.)
Battery Support
System Off Mode
Power Loss Control
Copyright © 2016 congatec AG
Options Description
Disabled
Disabled displays normal POST diagnostic messages.
Enabled Enabled displays OEM logo instead of POST messages.
Note: The default OEM logo is a dark screen.
Default: 1 Number of seconds to wait for setup activation key.
0 - 65535 0 means no wait for fastest boot (not recommended), 65535 means infinite wait.
On Select the keyboard numlock state.
Off
No Select whether the setup menu should be started if no boot device is connected.
Yes
No Select whether the popup boot menu can be started.
Yes
Type Based Select boot option priority selection method.
UEFI Standard
UEFI First Set boot option sorting method.
Legacy First UEFI First: Try all UEFI boot options before first legacy boot option.
Legacy First: Try all legacy boot options before first UEFI boot option.
Disabled This view is only available when in the default "Type Based" mode.
SATA 0 Drive
SATA 1 Drive When in "UEFI Standard" mode you will only see the devices that are currently connected to
NVMe Storage the system.
USB Harddisk
USB CDROM
Other USB Device
SD Card Storage
Local Area Network
Firmware-based Bootloader
Other Device
Auto (Battery Manager) Battery system support selection. Select ' Battery-Only On I2C Bus' for battery-only systems
Battery-Only On I2C Bus using I2C bus and ' Battery-Only On SMBus' for battery-only systems using SMBus. Select 'Auto'
Battery-Only On SMBus for systems equipped with a real battery system manager (connected via I2C or SMBus).
G3/Mech Off Define system state after shutdown when a battery system is present.
S5/Soft Off
Remain Off Specifies the mode of operation if an AC power loss occurs.
Turn On Remain Off keeps the power off until the power button is pressed.
Last State Turn On restores power to the computer.
Last State restores the previous power state before power loss occurred.
Note: Only works with an ATX type power supply.
TR33m10 101/105
