Pci Express Submenu - Congatec COM Express conga-TR3 User Manual

Feature
AMD PowerNow! Support
Startup P-State Adjustment
ACPI P-State Adjustment
NX Support
CPU Virtualization
C6 Support
Core Performance Boost
SMU TDP Configuration
11.3.16

PCI Express Submenu

Feature
PCI Settings
PCI Latency Timer
VGA Palette Snoop
PERR# Generation
Copyright © 2016 congatec AG
Options Description
Disabled Enable or disable support for AMD PowerNow! technology. Allows operating systems to control CPU
Enabled performance states.
P-State 0 Select the maximum CPU performance state to be set at power up. Higher numbers mean lower
P-State 1 performance. P-state 0 is the highest performance state.
P-State 2
P-State 0 Select the maximum CPU performance state the operating system should support. Higher numbers
P-State 1 mean lower performance. P-state 0 is the highest performance state.
P-State 2
Disabled Enable or disable the 'no-execute' page protection function.
Enabled
Disabled When enabled, a Virtual Machine Manager (VMM) can utilize the integrated hardware virtualization
Enabled support.
Disabled Enable or disable CPU C6 low power state support.
Enabled
Auto Control usage of boosted P-States, i.e. P-States above the standard CPU P-State limit. Availability
Disabled depends on CPU revision and type, actual usage on total CPU/GPU chip power consumption.
Auto Configure System Management Unit to keep CPU below selected TDP level.
12 W Auto means maximum TDP settings should be obtained from CPU.
15 W
25 W
35 W
Options Description
32 Select value to be programmed into PCI latency timer register.
64
96
128
160
192
224
248 PCI Bus Clocks
Disabled Enable or disable VGA palette registers snooping.
Enabled
Disabled Enable or disable PCI device to generate PERR#.
Enabled
TR33m10 87/105
