11

BIOS Setup Description

The following section describes the BIOS setup program. The BIOS setup program can be used to view and change the BIOS settings for the
module. Only experienced users should change the default BIOS settings.
11.1

Entering the BIOS Setup Program

The BIOS setup program can be accessed by pressing the <DEL> or <F2> key during POST.
11.1.1

Boot Selection Popup

The BIOS offers the possibility to access a Boot Selection Popup menu by pressing the <F11> key during POST. If this option is used, a
selection will be displayed immediately after POST allowing the operator to select either the boot device that should be used or an option to
enter the BIOS setup program.
11.2

Setup Menu and Navigation

The congatec BIOS setup screen is composed of the menu bar and two main frames. The menu bar is shown below:
Main Advanced
The left frame displays all the options that can be configured in the selected menu. Grayed-out options cannot be configured. Only the blue
options can be configured. When an option is selected, it is highlighted in white.
The right frame displays the key legend. Above the key legend is an area reserved for text messages. These text messages explain the options
and the possible impacts when changing the selected option in the left frame.
Note
Entries in the option column that are displayed in bold print indicate BIOS default values.
Copyright © 2016 congatec AG
Chipset Security Boot Save & Exit
