11.3.7

Trusted Platform Module 2.0 Submenu

Feature
Security Device Support
Active PCR banks
Available PCR banks
SHA-1 PCR Bank
SHA-256 PCR Bank
Pending operation
Platform Hierarchy
Storage Hierarchy
Endorsement Hierarchy
TPM2.0 UEFI Spec Version
Note
There are 2 different TPM menus, one for TPM 1.2 and another one is for TPM 2.0. Correct menu will be shown once TPM 1.2 or TPM 2.0
device is detected. UEFI OS must be used if TPM 2.0 support is required.
11.3.8

RTC Wake Submenu

Feature Options
RTC Wake Mode Disabled
Wake from S5 only
Wake from S4 and S5
Wake from S3, S4 and S5
Wake up hour
Wake up minute
Wake up second
Copyright © 2016 congatec AG
Options Description
Disable
Enable or disable BIOS support for security device.
Enable
No option List of active PCR banks
No option List of available PCR banks
Enabled Enable or disable SHA-1 PCR bank. This is a default PCRs compatible with TPM 1.2 and supported by
Disabled Windows 8.1 and newer OSes.
Enabled Enable or disable SHA-256 PCR bank. This is new PCRs specific to released TPM 2.0 standard.
Disabled Supported only by Windows 10 and newer OSes.
None Perform selected TPM 2.0 chip operation.
TPM Clear Note: System might restart several times during POST to perform selected operation.
Enabled Enable or disable TPM 2.0 platform hierarchy.
Disabled
Enabled Enable or disable TPM 2.0 storage hierarchy.
Disabled
Enabled Enable or disable TPM 2.0 endorsement hierarchy.
Disabled
TCG_2 Compatible UEFI specification version, SHA256 PCRs will not be exposed if TCG_1_2 is selected.
TCG_1_2
Description
Enable system to wake from specified Sx states using RTC alarm.
Specify wake up hour.
Specify wake up minute.
Specify wake up second.
TR33m10 81/105
