Feature
AT Shutdown Mode
UEFI Fast Boot
SATA Support
VGA Support
USB Support
PS/2 Device Support
Network Stack Driver Support
Redirection Support
UEFI Screenshot Driver
Note
1. The term 'AC power loss' stands for the state when the module loses the standby voltage on the 5V_SB pins. On congatec modules, the
standby voltage is continuously monitored after the system is turned off. If within 30 seconds the standby voltage is no longer detected, then
this is considered an AC power loss condition. If the standby voltage remains stable for 30 seconds, then it is assumed that the system was
switched off properly.
2. Inexpensive ATX power supplies often have problems with short AC power sags. When using these ATX power supplies it is possible that
the system turns off but does not switch back on, even when the PS_ON# signal is asserted correctly by the module. In this case, the internal
circuitry of the ATX power supply has become confused. Usually another AC power off/on cycle is necessary to recover from this situation.
11.5 Save & Exit Menu
Select the Save & Exit tab from the setup menu with the <Arrow> keys to enter the Save & Exit setup screen.
Copyright © 2016 congatec AG
Options Description
System Reboot Determines the behavior of an AT-powered system after a shutdown.
Hot S5
Disabled Enable or disable boot with initialization of a minimal set of devices required to launch active
Enabled boot option. Has no effect for BBS / legacy boot options.
Last Boot HDD Only Select which SATA device to be initialized in fast boot mode.
All SATA Devices
Auto If set to Auto, the legacy video option ROM will be installed for legacy OS boot; boot logo will
UEFI Driver NOT be shown during POST. For UEFI OS boot the UEFI GOP driver will be installed.
Disabled If set to Disabled, no USB device will be available before OS boot. If set to Partial Init, specific
Full Init USB ports/devices will NOT be available before OS boot. If set to Enabled, all USB devices will
Partial Init be available during POST and after OS boot.
Disabled If set to Disabled, PS/2 devices will be skipped.
Enabled
Disabled If set to Disabled, UEFI network stack driver installation will be skipped.
Enabled
Disabled
If set to Disabled, console redirection driver installation will be skipped.
Enabled
Disabled Enable or disable UEFI screenshot driver. If enabled, user can take BIOS Setup and UEFI
Enabled applications screenshots by pressing LCtrl+LAlt+F12. Screenshots will be saved on the first
writable FS in PNG format.
