Gigabit Ethernet Pin # Description
GBE0_CTREF
A14
Reference voltage for Carrier Board Ethernet channel 0 magnetics
center tap. The reference voltage is determined by the requirements
of the module PHY and may be as low as 0V and as high as 3.3V. The
reference voltage output shall be current limited on the module. In
the case in which the reference is shorted to ground, the current shall
be limited to 250mA or less.
Copyright © 2016 congatec AG
I/O
PU/PD Comment
Not connected
TR33m10
45/105
