Congatec COM Express conga-TR3 User Manual page 59

Signal Pin # Description
DDI2_DDC_AUX_SEL C34 Selects the function of DDI2_CTRLCLK_AUX+ and DDI2_CTRLDATA_AUX-.
This pin shall have a IM pull-down to logic ground on the module. If this input
is floating, the AUX pair is used for the DP AUX+/- signals. If pulled-high, the
AUX pair contains the CTRLCLK and CTRLDATA signals
DDI3_PAIR0+ C39 Multiplexed with DP3_LANE0+ and TMDS3_DATA2+.
DDI3_PAIR0- C40 Multiplexed with DP3_LANE0- and TMDS3_DATA2-.
DDI3_PAIR1+ C42 Multiplexed with DP3_LANE1+ and TMDS3_DATA1+.
DDI3_PAIR1- C43 Multiplexed with DP3_LANE1- and TMDS3_DATA1-.
DDI3_PAIR2+ C46 Multiplexed with DP3_LANE2+ and TMDS3_DATA0+.
DDI3_PAIR2- C47 Multiplexed with DP3_LANE2- and TMDS3_DATA0-.
DDI3_PAIR3+ C49 Multiplexed with DP3_LANE3+ and TMDS3_CLK+.
DDI3_PAIR3- C50 Multiplexed with DP3_LANE3- and TMDS3_CLK-.
DDI3_HPD C44 Multiplexed with DP3_HPD and HDMI3_HPD.
DDI3_CTRLCLK_AUX+ C36 Multiplexed with DP3_AUX+ and HDMI3_CTRLCLK.
DP AUX+ function if DDI3_DDC_AUX_SEL is no connect.
HDMI/DVI I2C CTRLCLK if DDI3_DDC_AUX_SEL is pulled high
DDI3_CTRLDATA_AUX- C37 Multiplexed with DP3_AUX- and HDMI3_CTRLDATA.
DP AUX- function if DDI3_DDC_AUX_SEL is no connect.
HDMI/DVI I2C CTRLDATA if DDI3_DDC_AUX_SEL is pulled high.
DDI3_DDC_AUX_SEL C38 Selects the function of DDI3_CTRLCLK_AUX+ and DDI3_CTRLDATA_AUX-.
This pin shall have a IM pull-down to logic ground on the module. If this input
is floating, the AUX pair is used for the DP AUX+/- signals. If pulled-high, the
AUX pair contains the CTRLCLK and CTRLDATA signals
Note
The conga-TR3 supports two DDI interfaces by default. A third DDI interface (optional DDI) can be supported via assembly option (customized
variant). Customized variants with 3 DDI interfaces do not support LVDS/eDP port. Additionally, they can only support two independent
HDMI/DVI displays.
The DDI interfaces support dual-mode DisplayPort. To support HDMI/DVI, an external level shifter (PTN3360D) should be implemented on
the user's carrier board.
Copyright © 2016 congatec AG
I/O
I 3.3V
O PCIE
O PCIE
O PCIE
O PCIE
I 3.3V
I/O PCIE
OD 3.3V
I/O PCIE
I/OD 3.3V
I 3.3V
TR33m10
PU/PD Comment
PD 1M
Not supported by default
Not supported by default
Not supported by default
Not supported by default
PD 100K Not supported by default
PD 100k Not supported by default
PU 100k Not supported by default
PD 1M Not supported by default
59/105
