Feature
Link Speed
ASPM Mode Control
Hotplug Mode Control
PEG Port 2
Link Speed
ASPM Mode Control
Hotplug Mode Control
11.3.16.3 PIRQ Routing & IRQ Reservation Submenu
Feature
PIRQA
PIRQB
PIRQC
PIRQD
PIRQE
PIRQF
Copyright © 2016 congatec AG
Options Description
Max supported Select PEG port 1 link speed. Max supported = link speed determined by PCIe device.
Gen3 GenX = force GenX speed
Gen2
Gen1
Disabled Select ASPM mode for current PCIe port
L0s Entry
L1 Entry
L0s And L1 Entry
Disabled Enable or disable hotplug on current PCIe port.
Enabled
Disabled Enable or disable PEG port 2.
Enabled
Max supported Select PEG port 2 link speed. Max supported = link speed determined by PCIe device.
Gen3 GenX = force GenX speed
Gen2
Gen1
Disabled Select ASPM mode for current PCIe port
L0s Entry
L1 Entry
L0s And L1 Entry
Disabled Enable or disable hotplug on current PCIe port.
Enabled
Options Description
Auto Set interrupt for selected PIRQ. Please refer to the board's resource list for a detailed list of devices
IRQ3 connected to the respective PIRQ.
IRQ4 NOTE: These settings will only be effective while operating in PIC (non-IOAPIC) interrupt mode.
IRQ10
IRQ11
IRQ14
IRQ15
Same as PIRQA Same as PIRQA
Same as PIRQA Same as PIRQA
Same as PIRQA Same as PIRQA
Same as PIRQA Same as PIRQA
Same as PIRQA Same as PIRQA
TR33m10 91/105
