Feature
LVDS SSC
Remove EDID Established
Timings
Remove EDID Standard
Timings
Ensure EDID Vsync Pulse
Width >=3
DDI1 Interface
DDI2 Interface
11.3.3

Hardware Monitoring Submenu

Feature
CPU Temperature
Board Temperature
DC Input Voltage Standard
5V Standby
DC Input Current
CPU Fan Speed
Fan PWM Frequency Mode
Fan PWM Frequency
Default Fan Speed
Copyright © 2016 congatec AG
Options
Disabled
0.5%
1.0%
1.5%
2.0%
2.5%
Yes
No
Yes
No
Yes
No
Disabled
Auto Selection
Force HDMI/DVI
Disabled
Auto Selection
Force HDMI/DVI
Options Description
No option Displays the actual module CPU temperature in °C.
No option Displays the actual module board temperature in °C.
No option Displays the actual voltage of DC power supply.
No option Displays the actual voltage of the 5V standby power supply.
No option Displays the module input current from DC power suply.
No option Displays the actual CPU Fan Speed in RPM.
Low Frequency Select fan PWM base frequency mode.
High Frequency Low frequency: 11.0Hz-88.2Hz
High frequency: 1kHz-63kHz
31 Khz Select fan PWM base frequency.
Default: 60% Default fan speed to be set after the OS takes fan control.
10 – 100%
Description
Configure LVDS spread spectrum clock modulation depth using center spreading and a fixed
modulation frequency of 32.9kHz
Modify EDID data to remove established timings (bytes 0x23 – 0x25), which aren't required for LVDS
panels.
This modification will only be applied for EDID data stored on flash.
Modify EDID data to remove standard timings (bytes 0x26 – 0x35), which aren't required for LVDS
panels.
This modification will only be applied for EDID data stored on flash.
Modify EDID data to ensure Vsynce Pulse Width (byte 0x40) is at least 3, which is required for LVDS
panels. This modification will only be applied for EDID data stored on flash.
Configure the digital display interface 1. Display Port or HDMI/DVI supported and automatically
detected and configured, or HDMI/DVI mode can be forced.
Configure the digital display interface 2. Display Port or HDMI/DVI supported and automatically
detected and configured, or HDMI/DVI mode can be forced.
TR33m10 76/105
