2.5
Power Consumption
The power consumption values were measured using the following test setup:
• conga-TR3 COM
• modified carrier board to measure the power consumption of the COM
• product specific cooling solution with the highest cooling capacity
• running Windows OS
Note
All peripherals were powered externally and therefore did not influence the measured values.
The power consumption values were recorded during the following S-states:
Table 4
System State Description
System State
S0: Minimum value
S0: Maximum value
S0: Peak value
S3
S5
Copyright © 2016 congatec AG
Description
COM set to lowest frequency mode (LFM) with minimum core voltage during
desktop idle. The CPU was stressed to its maximum frequency in this S-state.
COM set to highest frequency mode (HFM/Turbo Boost). The CPU was
stressed to its maximum frequency in this S-state.
The worst case power consumption value shows the peak value over a
short period of time. Highest power spike during the measurement of
"S0: Maximum value". This value should be taken into consideration when
designing the system's power supply to ensure that the power supply is
sufficient during worst case scenarios
COM is powered by VCC_5V_SBY.
COM is powered by VCC_5V_SBY.
TR33m10
15/105
