Feature
Data Bits
Baudrate
11.3.24

PC Speaker Configuration Submenu

Feature
Debug Beeps
Input Device Debug Beeps
Output Device Debug Beeps
USB Driver Beeps
11.3.25 Intel I211 Gigabit Network Connection Submenu
®
Feature
► NIC Configuration
Blink LEDs
UEFI Driver
Adapter PBA
Chip Type
PCI Device ID
PCI Address
Link Status
Copyright © 2016 congatec AG
Options Description
8 Data Bits Select data bits count of BC diagnostic console interface.
7 Data Bits
6 Data Bits
5 Data Bits
1200 Baud Select baudrate of of BC diagnostic console interface.
2400 Baud
4800 Baud
9600 Baud
19200 Baud
38400 Baud
Options Description
Disabled Enable or disable general debug / status beep generation.
Enabled
Disabled Enable or disable input device debug beeps.
Enabled
Disabled
Enable or disable output device debug beeps.
Enabled
Disabled Enable or disable USB driver beeps.
Enabled
Options Description
Submenu Opens the NIC Configuration submenu.
Default: 0 The Ethernet activity LEDs will blink as many seconds as entered.
0 - 15
No option Displays the UEFI Driver version.
No option Displays the Adapter PBA.
No option Displays the type of Ethernet chip.
No option Displays the PCI Device ID of the Ethernet controller.
No option Displays the PCI Bus:Device:Function number of the Ethernet controller.
No option Displays the Link Status.
TR33m10 97/105
