Feature
Serial Port 0
Device Settings
Serial Port 1
Device Settings
Parallel Port
Device Settings
Device Mode
Note
This setup menu is only available if an external Winbond W83627 Super I/O has been implemented on the carrier board.
11.3.14

Serial Port Console Redirection Submenu

Feature
COM0
Console Redirection
►Console Redirection Settings
COM1
Console Redirection
►Console Redirection Settings

11.3.14.1 Console Redirection Settings Submenu

Feature
Terminal Type
Copyright © 2016 congatec AG
Options Description
Disabled Enable or disable serial port 0.
Enabled
IO=3F8h; IRQ=4; Fixed configuration of serial port 0 if enabled.
Disabled Enable or disable serial port 1.
Enabled
IO=2F8h; IRQ=3; Fixed configuration of serial port 1 if enabled.
Disabled Enable or disable parallel port.
Enabled
IO=378h; IRQ=7; Fixed configuration of the parallel port if enabled.
Standard Parallel Mode Set the parallel port mode.
EPP Mode
ECP Mode
EPP Mode & ECP Mode
Options Description
Disabled Enable or disable serial port 0 console redirection.
Enabled
Submenu Opens console redirection configuration sub menu.
Disabled Enable or disable serial port 1 console redirection.
Enabled
Submenu Opens console redirection configuration sub menu.
Options Description
VT100 Select terminal type.
VT100+
VT-UTF8
ANSI
TR33m10 85/105
