2.5.3

conga-TR3 AMD Embedded RX-216GD 1.6/3.0 GHz Dual Core 1MB L2 Cache

Table 7 Part No. 041302
Part No. 041302 (R5 Graphics)
Max Turbo Frequency
Memory Size
Operating System
Power State
Power consumption
Note
All recorded power consumption values are approximate and only valid for the controlled environment described earlier. 100% workload
refers to the CPU workload and not the maximum workload of the complete module. Supply power for S3 mode is 5V while all other measured
modes are supplied with 12V power. Power consumption results will vary depending on the workload of other components such as graphics
engine, memory, etc.
2.6

Supply Voltage Battery Power

• 2.3V - 3.5V DC
• Typical 3V DC
2.6.1

CMOS Battery Power Consumption

Table 8 CMOS Battery Power Consumption
The CMOS battery power consumption value listed above should not be used to calculate CMOS battery lifetime. You should measure the
CMOS battery power consumption in your customer specific application in worst case conditions, for example during high temperature and
high battery voltage. The self-discharge of the battery must also be considered when determining CMOS battery lifetime. For more information
about calculating CMOS battery lifetime refer to application note AN9_RTC_Battery_Lifetime.pdf, which can be found on the congatec AG
website at www.congatec.com.
Copyright © 2016 congatec AG
AMD Embedded RX-216GD 1.6GHz Dual Core 1MB L2 Cache (28nm) Hardware revision A.0 /BIOS revision TR3R016
3.0GHz
2x 4GB
Windows 7 (64 bit)
S0: Min S0: Max
0.4 A /4.78 W 3.72 A /44.63 W
RTC: measured with conga-TR3/421BD
-10°C
20°C
70°C
S0: Peak S3
5.27 A /63.21 W 0.08 A /0.41 W
Voltage Current
3V DC 2,19 µA
3V DC 2,84 µA
3V DC 4,77 µA
TR33m10
S5
0.06 A /0.32 W
