9.1
A-B Connector Signal Descriptions
Table 12
High Definition Audio Link Signals Descriptions
Signal
Pin #
AC/HDA_RST#
A30
AC/HDA_SYNC
A29
AC/HDA_BITCLK
A32
AC/HDA_SDOUT
A33
AC/HDA_SDIN[2:0] B28-B30 High Definition Audio Serial Data In [0]: These signals are serial TDM data inputs from
Table 13
Testing
Table 14
Gigabit Ethernet Signal Descriptions
Gigabit Ethernet Pin # Description
GBE0_MDI0+
GBE0_MDI0-
GBE0_MDI1+
GBE0_MDI1-
GBE0_MDI2+
GBE0_MDI2-
GBE0_MDI3+
GBE0_MDI3-
GBE0_ACT#
GBE0_LINK#
GBE0_LINK100#
GBE0_LINK1000#
Copyright © 2016 congatec AG
Description
High Definition Audio Reset: This signal is the master hardware reset to external codec(s). O 3.3VSB
High Definition Audio Sync: This signal is a 48 kHz fixed rate sample sync to the codec(s).
It is also used to encode the stream number.
High Definition Audio Bit Clock Output: This signal is a 24.000MHz serial data clock
generated by the High Definition Audio controller.
High Definition Audio Serial Data Out: This signal is the serial TDM data output to the
codec(s). This serial output is double-pumped for a bit rate of 48 Mb/s for High Definition
Audio.
the three codecs. The serial input is single-pumped for a bit rate of 24 Mb/s for High
Definition Audio.
A13
Gigabit Ethernet Controller 0: Media Dependent Interface Differential
A12
Pairs 0, 1, 2, 3. The MDI can operate in 1000, 100, and 10Mbit/sec
A10
modes. Some pairs are unused in some modes according to the
A9
following:
A7
1000
A6
MDI[0]+/-
B1_DA+/-
A3
MDI[1]+/-
B1_DB+/-
A2
MDI[2]+/-
B1_DC+/-
MDI[3]+/-
B1_DD+/-
B2
Gigabit Ethernet Controller 0 activity indicator, active low.
A8
Gigabit Ethernet Controller 0 link indicator, active low.
A4
Gigabit Ethernet Controller 0 100Mbit/sec link indicator, active low.
A5
Gigabit Ethernet Controller 0 1000Mbit/sec link indicator, active low.
I/O
I/O
Analog
100
10
TX+/-
TX+/-
RX+/-
RX+/-
O 3.3VSB
O 3.3VSB
O 3.3VSB
O 3.3VSB
TR33m10
I/O
PU/PD Comment
AC'97 codecs are not supported.
O 3.3VSB
AC'97 codecs are not supported.
O 3.3VSB
AC'97 codecs are not supported.
O 3.3VSB
AC'97 codecs are not supported.
I 3.3VSB
PD 47K
AC'97 codecs are not supported.
PU/PD Comment
Twisted pair signals for external transformer.
44/105
