Feature
Isolate SMBus Segments
11.3.11

SATA Submenu

Feature
SATA Controller
SATA Mode Selection
SATA Hot-Removal Support
SATA Port 0 State
Speed Limit
ESATA Support
SATA Port 1 State
Speed Limit
ESATA Support
SATA Port 0
SATA Port 1
11.3.12

ACPI Submenu

Feature
Hibernation Support
Copyright © 2016 congatec AG
Options Description
Never Allows isolation of off-module SMBus from internal SMBus.
During POST
Always
Options Description
Disabled Enable or disable the onboard SATA controller.
Enabled
Legacy IDE Select onboard SATA controller mode. Select legacy IDE mode if your OS doesn't allow interrupt
Native IDE sharing.
AHCI
Disabled Enable or disable hot removal of SATA devices (AHCI mode only)
Enabled
Enabled Enable or disable SATA port 0.
Disabled
Auto Select max. SATA speed generation for the selected port.
Gen1 Auto = up to Gen3
Gen2
Disabled Enabled or disable ESATA and hotplug (AHCI mode only) support.
Enabled
Enabled Enable or disable SATA port 1.
Disabled
Auto Select max. SATA speed generation for the selected port.
Gen1 Auto = up to Gen3
Gen2
Disabled Enabled or disable ESATA and hotplug (AHCI mode only) support.
Enabled
No option SATA drive 0 information.
No option SATA drive 1 information.
Options Description
Disabled Enable or disable system ability to hibernate (operating system S4 sleep state). This
Enabled option may not be effective with some operating systems.
TR33m10 83/105
