The setup program uses a key-based navigation system. Most of the keys can be used at any time while in setup. The table below explains the
supported keys:
Key
← → Left/Right
↑ ↓ Up/Down
+ - Plus/Minus
Tab
F1
F2
F9
F10
ESC
ENTER
11.3

Main Setup Screen

When you first enter the BIOS setup, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main
tab. The Main screen reports BIOS, processor, memory and board information and is used to configure the system date and time.
Feature
Main BIOS Version
OEM BIOS Version
Build Date
Product Revision
Serial Number
BC Firmware Rev.
MAC Address
Boot Counter
Running Time
Memory Information
Total Memory
System Date
System Time
Copyright © 2016 congatec AG
Description
Select a setup menu (e.g. Main, Boot, Exit).
Select a setup item or sub menu.
Change the field value of a particular setup item.
Select setup fields (e.g. in date and time).
Display General Help screen.
Load previous settings.
Load optimal default settings.
Save changes and exit setup.
Discard changes and exit setup.
Display options of a particular setup item or enter submenu.
Options
No option
No option
No option
No option
No option
No option
No option
No option
No option
No option
No option
Day of week, month/day/year
Hour:Minute:Second
Description
Displays the main BIOS version.
Displays the additional OEM BIOS version.
Displays the date the BIOS was built
Displays the hardware revision of the board.
Displays the serial number of the board.
Displays the revision of the congatec board controller.
Displays the MAC address of the onboard Ethernet controller.
Displays the number of boot-ups. (max. 16777215).
Displays the time the board is running [in hours max. 65535].
Displays the total amount of installed memory.
Specifies the current system date. Note: The date is in month-day-year format.
Specifies the current system time. Note: The time is in 24-hour format.
TR33m10 72/105
