5
Onboard Temperature Sensor
Board Temperature Sensor:
Onboard the conga-TR3 is a sensor that measures the temperature of the board. The board sensor is located at the top of the conga-TR3 and
is defined in CGOS API as CGOS_TEMP_BOARD. The sensor positions are designated as U2 and T1 as shown below:
X3
T1
U1
U2
51.21
103.53
All dimensions in mm
Copyright © 2016 congatec AG
TR33m10
24/105
