Feature
Baudrate
Data Bits
Parity
Stop Bits
Flow Control
VT-UTF8 Combo Key Support
Recorder Mode
Resolution 100x31
Legacy OS Redirection Resolution
Putty KeyPad
Redirection After BIOS POST
11.3.15
CPU Submenu
Feature
►CPU Information
Copyright © 2016 congatec AG
Options
Description
9600
Select baud rate.
19200
38400
57600
115200
7
Set number of data bits.
8
None
Select parity.
Even
Odd
Mark
Space
1
Set number of stop bits.
2
None
Select flow control.
Hardware RTS/CTS
Disabled
Enable VT-UTF8 combination key support for ANSI/VT100 terminals
Enabled
Disabled
With recorder mode enabled, only text output will be sent over the terminal. This is helpful to capture
Enabled
and record terminal data.
Disabled
Enables or disables extended terminal resolution
Enabled
80x24
Number of rows and columns supported for legacy OS redirection.
80x25
VT100
Select FunctionKey and KeyPad on Putty.
LINUX
XTERMR6
SCO
ESCN
VT400
Enabled
Select whether serial redirection should be continued after POST.
Disabled
Options
Description
No option
Submenu with various information about CPU and caches
TR33m10
86/105
