8.7
Boot Setup
Select the Boot tab from the setup menu to enter the Boot setup screen.
8.7.1
Boot Settings Configuration
Feature
Quiet Boot
Setup Prompt Timeout
Bootup NumLock State
Power Loss Control
Enter Setup If No Boot Device
Enable Popup Boot Menu
Boot Priority Selection
Boot Option Sorting Method
1st, 2nd, 3rd, ...
Boot Device
(Up to 12 boot devices can be prioritized
if "UEFI Standard" priority list control is
selected. If "Type Based" priority list control
is enabled only 8 boot devices can be
prioritized.)
Copyright © 2016 congatec AG
Options
Description
Disabled
Enable this feature to display OEM logo instead of POST messages.
Enabled
Note: The default OEM logo is a dark screen.
1
Set number of seconds to wait for a setup activation key:
(more values)
'65535' - Waits indefinitely (0xFFFF).
'0' - Disables waiting (not recommended).
On
Set the keyboard numlock state.
Off
Remain Off
Set the mode of operation if an AC power loss occurs:
Turn On
'Remain Off' - Keeps the power off until the power button is pressed.
Last State
'Turn On' - Restores power to the computer.
'Last State' - Restores the power state before power loss occurred.
Note: This feature only works with an ATX type power supply.
No
Set whether the setup menu should be started if no boot device is connected.
Yes
No
Set whether the popup boot menu can be started.
Yes
UEFI Standard
'UEFI Based' - Select boot priority from a list of currently detected devices.
Type Based
'Type Based' - Select boot priority from a list of device types even if they are not connected yet.
Legacy First
Set boot option sorting method:
UEFI First
'UEFI First' - Tries all UEFI boot options before first legacy boot option.
'Legacy First' Tries all Legacy boot options before first UEFI boot option.
Disabled
This view is only available in the default "Type Based" mode.
SATA 0 Drive
In "UEFI Standard" mode, you will only see the devices that are connected to the system.
SATA 1 Drive
USB Harddisk
USB CDROM
Other USB Device
Onboard SD Card Storage
Onboard LAN
External LAN
Firmware-based Bootloader
Other Device
ICSLm13.indd
91/95
