Feature
Link Speed
ASPM Mode Control
Hotplug Mode Control
PCIe Port 3
Link Speed
ASPM Mode Control
Hotplug Mode Control
PCIe Port 4
Link Speed
ASPM Mode Control
Hotplug Mode Control
PEG Port Organization
PEG Port 1
Copyright © 2016 congatec AG
Options Description
Max supported Select PCIe port 2 link speed. Max supported = link speed determined by PCIe device.
Gen3 GenX = force GenX speed
Gen2
Gen1
Disabled Select ASPM mode for current PCIe port
L0s Entry
L1 Entry
L0s And L1 Entry
Disabled Enable or disable hotplug on current PCIe port.
Enabled
Disabled Enable or disable PCIe port 3.
Enabled
Max supported Select PCIe port 3 link speed. Max supported = link speed determined by PCIe device.
Gen3 GenX = force GenX speed
Gen2
Gen1
Disabled Select ASPM mode for current PCIe port
L0s Entry
L1 Entry
L0s And L1 Entry
Disabled Enable or disable hotplug on current PCIe port.
Enabled
Disabled Enable or disable PCIe port 4.
Enabled
Max supported Select PCIe port 4 link speed. Max supported = link speed determined by PCIe device.
Gen3 GenX = force GenX speed
Gen2
Gen1
Disabled Select ASPM mode for current PCIe port
L0s Entry
L1 Entry
L0s And L1 Entry
Disabled Enable or disable hotplug on current PCIe port.
Enabled
1 x8 Port
Select PEG port(s) layout
2 x4 Ports
Disabled Enable or disable PEG port 1.
Enabled
