11.6
Boot Setup
Select the Boot tab from the setup menu to enter the Boot setup screen.
Boot Settings Configuration
11.6.1
Feature
Quiet Boot
Setup Prompt Timeout
Bootup NumLock State
System Off Mode
Power Loss Control
AT Shutdown Mode
Enter Setup If No Boot
Device
Enable Popup Boot
Menu
Boot Priority Selection
Copyright © 2013 congatec AG
Options
Description
Disabled
Disabled displays normal POST diagnostic messages.
Enabled
Enabled displays OEM logo instead of POST messages.
Note: The default OEM logo is a dark screen.
1
Number of seconds to wait for setup activation key.
0 means no wait for fastest boot (not recommended), 65535 means infinite wait.
0 - 65535
On
Select the keyboard numlock state.
Off
Define system state after shutdown when a battery system is present.
G3/Mech Off
S5/Soft Off
Specifies the mode of operation if an AC power loss occurs.
Remain Off
Turn On
Remain Off keeps the power off until the power button is pressed.
Last State
Turn On restores power to the computer.
Last State restores the previous power state before power loss occurred.
Note: Only works with an ATX type power supply.
System Reboot
Determines the behavior of an AT-powered system after a shutdown.
Hot S5
No
Select whether the setup menu should be started if no boot device is connected.
Yes
No
Select whether the popup boot menu can be started.
Yes
Device Based
Select between device and type based boot priority lists. The "Device Based" boot priority list allows you to select from
Type Based
a list of currently detected devices only. The "Type Based" boot priority list allows you to select device types, even if a
respective device is not yet present. Moreover, the "Device Based" boot priority list might change dynamically in cases
when devices are physically removed or added to the system. The "Type Based" boot menu is static and can only be
changed by the user.
TU87m12
107/114
