8.7.1

Boot Settings Configuration

Feature
Setup Prompt Timeout
Bootup NumLock State
Quiet Boot
Enter Setup If No Boot
Device
Enable Popup Boot
Menu
Boot Priority Selection
Boot Option Sorting
Method
Power Loss Control
AT Shutdown Mode
System Off Mode
Fast Boot
Copyright © 2016 congatec AG
Options
Description
Default: 1
Set number of seconds to wait for setup activation key.
0 - 65535
'65535' - Waits indefinetly (0xFFFF).
'0' - Does not wait (not recommended).
On
Set the keyboard numlock state.
Off
Disabled
'Disabled' - Displays normal POST diagnostic messages.
Enabled
'Enabled' - Displays OEM logo instead of POST messages.
Note: The default OEM logo is a dark screen.
No
Select whether the setup menu should be started if no boot device is connected.
Yes
No
Select whether the popup boot menu can be started.
Yes
Device Based
Set boot priority:
Type Based
'Device Based' - Set boot priority from a list of currently detected devices.
'Type Based' - Set boot priority from a list of device types even if they are not connected yet.
Legacy First
Set boot option sorting method:
UEFI First
'Legacy First' - Tries all legacy boot option first before first UEFI boot option.
'UEFI First' - Tries all UEFI boot options before first legacy boot option.
Remain Off
Select the mode of operation if an AC power loss occurs:
Turn On
'Remain Off' - Keeps the power off until the power button is pressed.
Last State
'Turn On' - Restores power to the computer.
'Last State' - Restores the previous power state before power loss occurred.
Note: Please chose an ATX type power supply if you want to use this feature.
System Reboot
Select the behavior of an AT-powered system after a shutdown.
Hot S5
G3/Mech Off
Select the system state after a shutdown if a battery system is connected.
S5/Soft Off
Disabled
Enable this feature to boot with a minimum set of devices.
Note: This feature has no effect on BBS / legacy boot options.
Enabled
IA40m12.indd
90/97
